3 Axis CNC Intersecting Plasma Flame Pipe Cutting Machine with High-end Technical Program

Instructions:

1. Mainly applies to the thermal cutting of intersecting and top part of the different pipe systems.
2. Materials of the working piece: low carbon steel, (Attention: copper-nickel tubes and the stainless steel pipe should use plasma cutting.
3. Can cut ordinary steels (CNC flame/plasma cutting machine) and realize absolute flame/plasma steel cutting. CNC intersecting pipe cutting machines can realize various functions.

Axis Parameters:

Working environment:
Temperature: -5~40 ℃;
Humidity: ≤90%;
Power supply: 220V±10% 50Hz

Products features:

1) Standard version not only can both flame cutting and plasma cutting, but also can cut both pipe and steel plate.

2) Using AC 3 phase high voltage step motor drive technology, the motors get more power but less nosiy.

3) Can make interesting pipe hole cutting in different directions and different diameters.

4) Can cut oblique section of the pipe.

5) Can cut branch intersecting pipe's end socket for main pipe.

6) Can cut square and slotted hole and all shapes on the pipe.

7) Can cut off the pipe.

8) Can cut dual bending ends for bending of the pipe after welding.

Transmission and cutting modes:
Transmission of the CNC cutting steel: Chuck type structure
Cutting mode: Plasma Cutting
THC mode: Electric Motion

Main parts of the machines:

Main precision requirements:
The working piece should conform to the national standards.The positioning precision of the working length: 0.2mm/2000mm; Positioning precision of the bus bar: ≤±0.5mm; Tolerance of the space between pipe heads: ≤±0.5 mm.

1) Revolving drive motion
Driving System: Auxiliary drive of the precision gear box and the gear.
Revolving Speed: 0.1-25 r/min
Restoration Precision: ±0.3mm

2) Movements of the torch trolley
Driving System: Precision Gear Box (Domestic made); Transmission of the gear and track.
Effective Route: Same as the L1
Precision of the restoration: ±0.2mm

Working pieces:

Safety devices:

Collision-proofing device and limit switch.

Limit self-locking device in the software.
Emergency stop switch in the control box.

Package:

Metalwork Machinery (Wuxi) Co., LTd., was established in 2006, specializing in cutting and welding automation manufacture, sales, and services with more than 10 years experience.

Our products ranges: CNC flame and plasma cutting machine, CNC fiber laser cutting machine, arc welding machine, automatic resistance welding machine, automatic seam welding machine, H beam and box beam production line, robotics welding and cutting stations, etc.  We also can produce the customized machine according to customer's workpiece.

Moreover, we are specialized in "whole solution" of production lines for our customers, we not only supply you the individual equipment, but also delivery a solution for your project. This will bring you more values from us.

With regard to the welding equipment industry, advanced technical well-know in design and production activities and long term experience, we provide important technology and innovations for tank, pressure vessel, boiler,ship building, nuclear power, electric power station, manufacturing processes. We not only sell the equipment, but also delivery value to customers.

Service is our specialty, after long time cooperation, you will satisfy more with us.

If you have any queries, please do not hesitate to contact us by phone or E-mail. We will revert to your questions, within 24 hours after your requests.
